KTP Series Reed Relay
The KTP Series is a high-voltage, high-insulation reed relay designed for precision switching in demanding applications requiring elevated isolation and low leakage. Capable of switching up to 2,500 VDC, with breakdown voltages up to 6 kVDC and isolation voltages up to 7 kVDC, the KTP Series delivers robust performance in compact surface-mount (SMD) and through-hole (THT) formats.
Encapsulated in a rugged thermoset overmolded package, the KTP Series features SPST-NO (Form A) contact configurations and supports coil voltages of 5 VDC, 12 VDC, and 24 VDC. With insulation resistance exceeding 10¹³ Ω, it ensures ultra-low leakage currents, making it ideal for high-voltage switching in medical, test & measurement, and energy systems. Testing according to AEC-Q200 standards is planned and UL listed, the KTP Series is a reliable solution for high-performance designs.
- High-voltage switching up to 2,500 VDC
- Breakdown voltage up to 6 kVDC; isolation voltage up to 7 kVDC
- High insulation resistance >10¹³ Ω for low leakage performance
- SPST-NO (Form A) contact configuration
- Rated for up to 100 W and 1.0 A
- Coil voltage options: 5 VDC, 12 VDC, 24 VDC
- Available in surface-mount (SMD) and through-hole (THT) formats
- Rugged thermoset overmolded package for durability
- AEC-Q200 testing planned and UL listed for compliance
| Coil Voltage (VDC) | 5, 12, 24 |
| Coil Resistance (Ω) | 65-1800 |
| Contact Form | 1A (SPST) Normally Open (N.O.) |
| Rated Power Max. | 100W/2500VDC/1A |
- Automated Test Equipment (ATE): High-voltage switching in test systems
- Medical Devices: Defibrillators, imaging systems, and isolation circuits
- Battery-Powered Devices: Safe switching in portable electronics
- Photovoltaics: High-voltage relay control in solar energy systems
- Telecommunications: Isolation and switching in network infrastructure
- Mercury Relay Replacement: Clean, reliable alternative for legacy systems
